Brother DSmobile DS-940DW Wireless, 2-sided Portable Document Scanner

Wireless scan and go with the DSmobile DS-940DW. Versatile and truly portable with built-in rechargeable battery. Staying on top of your paperwork when you are out of the office is simple.

SRP £202.80 Inc. VAT

SRP £169.00 Ex. VAT

Automatic 2-sided A4 scanning up to 15 pages per minute

Space saving ‘U-path’ paper feed system

Industry leading software to scan documents, receipts and ID cards

Product Overview

Brother DSmobile DS-940DW mobile scanner facing forward open with document

Power directly from a USB 3.0 port on PC

Built-in rechargeable battery and card reader

Connect to a wireless network or Brother mobile app

Key features

  • Automatic 2-sided A4 scanning up to 15 pages per minute
  • Space saving ‘U-path’ paper feed system
  • Industry leading software to scan documents, receipts and ID cards
  • Power directly from a USB 3.0 port on PC
  • Built-in rechargeable battery and card reader
  • Connect to a wireless network or Brother mobile app

About this product:

The DSmobile DS-940DW is engineered to be truly flexible. Featuring a built-in battery, Wi-Fi and intuitive LCD panel, setup is effortless. Digitising your files whether in the office where space is limited or out on the road is simple.

Scan your documents straight to the cloud using Brother's mobile app and easily share your documents with colleagues wherever you are. Your information is kept safe, effortless to find and more convenient to edit.

With a unique "U-path" roller system, you are not required to have extra space behind the scanner for the document to feed-through. As the document goes in, it glides over the top of the scanner and is returned to you.



Specifications

General

Usage type Mobile
Battery Lithium
Control panel LED display, LED, Keys

Connectivity

USB interface Super Speed micro USB (Bus powered) 3.0 Type B
Wi-Fi Direct Yes
Wireless network interface WLAN IEEE 802.11b/g/n (Infrastructure Mode) IEEE 802.11g (Wi-Fi Direct)

Dimensions & weights

With carton 377 W x 162 D x 76 H mm
With carton Western Europe: 1076g, Eastern Europe & Nordics: 1109 g
Without carton 319 W x 63.1 D x 45.4 H mm
Weight 699 g

Energy Consumption

Power Consumption - ready mode Up to 2.2 W (Wi-Fi mode), 1.5 W (PC mode)
Operating Up to 3.6 watts
Off 0.11 watts
Sound power 53 dB
Sound pressure 42 dBA

Environment

Operating humidity 20 - 80%
Operating temperature 5 - 35C

In the box

Others DSmobile DS-940DW scanner, Micro USB Cable, Warranty, Quick setup giude, Product safety guide

Media specifications

Types and sizes Media size single width 50.8 - 215.9mm, length 86.4 - 1828.8mm, ("U-path" width 74 - 215.9mm, length 105 - 297mm), Card width 85.6 length 53.98mm, Card thickness with embossed 1.24mm, Plastic card up to 1mm thickness, Receipt width 74 - 79.38mm length 105 - 355.6mm
Weights 35 - 270 gsm, "U-path" 52 - 80 gsm

Network

IPv4 Yes
IPv6 Yes
Network protocols DHCP, APIPA (Auto IP), WINS/NetBIOS, DNS Resolver, mDNS, SNMPv1/v2c, ICMP, Web Services(Scan), HTTP/HTTPS server, LLMNR responder,SNTP Client
Wireless network IEEE 802.11 b/g/n
Wireless network security WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES)

Operating systems & software

Software supplied - Mac iPS for macOS, Remote Setup, NewSoft® Presto!® BizCard 7
Software supplied - Windows iPS for Windows PC, Nuance® PaperPort SE 14,Kofax Power PDF Standard v3, Remote Setup, NewSoft® Presto!® BizCard 6

Scanning

2-Sided scan Yes
A4 Scan Speed Colour and mono 15ppm, (A4 300dpi)
Duplex Scanning Speed Colour 30ipm, (A4 300dpi)
Scan to Email, OCR, file, image and microSD
Drivers Windows: TWAIN, WIA, Windows 7, 8.1, 10 (32 & 64 bit editions), Windows Server 2019, 2016, 2012R2, 2012, macOS: ICA 10.12.x, 10.13.x, 10.14.x, Linux: SANE. For latest firmware, software updates and compatibility for O.S, please visit http://support.brother.com.
Greyscale 256
Interpolated scan resolution 1200 x 1200 dpi

Supplies and accessories

Optional accessories Carrier sheet (CSA-3401)

Warranty

Warranty 12 months
Show more
Show less

Support

Woman sat at a desk on a laptop

Downloads & Drivers

Download and install the latest drivers and software for your Brother products.

View Downloads
Man and a woman sat a desk on a laptop

FAQs

Find the answers to our most frequently asked questions and troubleshooting here.

View FAQs
Man sat on a sofa working on a tablet

Manuals & Guides

Download the latest manuals and user guides for your Brother products

View Manuals

More about this product

Engineer wearing yellow hard hat and high-vis vest kneeling down with clipboard, with Brother DSmobile DS-940DW portable document scanner in enginnering room

Enjoy scanning anywhere

Truly portable, the DSmobile DS-940DW scanner has a built-in battery so you can enjoy scanning your documents without the need to plug into a power supply. Simply take your scanner with you, scanning where it’s most convenient for you.

Close up of LCD and buttons on Brother DSmobile DS-940DW portable document scanner

Stay effortlessly organised

Using Brother’s free mobile app, viewing and sharing documents on your mobile phone or tablet is effortless. The intuitive LCD panel makes selecting and changing scan functions simple.

Female with brown hair at reception with laptop using Brother DSmobile DS740D portable document scanner with boxes, delivery person, clip board

Convenient and space saving

The DSmobile DS-940DW is small and compact, ideal where space is limited. The unique “U-path” paper feed means you are not required to have extra space behind the scanner for the document to feed-through. As the document goes in, it glides over the top of the scanner and returned to you.

Brother DSmobile DS-940DW portable document scanner with ID card in scanner

Mixed media, high-quality results

Designed to scan a wide range of documents including A4 documents, ID cards and receipts, makes the DSmobile DS-940DW a true work companion.

The dedicated roller system, ensures your documents are smoothly fed-through, guaranteeing high-quality, digital files are created every time.

Customer Reviews

DS-940DW is rated 3.8 out of 5 by 41.
Rated 4 out of 5 by from Its ok Not as easy as it says to install. Created some issues. Having to spend a LOT of time figuring out how to get the receipts to download into separate files -- as it claims
Date published: 2022-05-09
Rated 5 out of 5 by from Great piece of kit. So easy and practical as a peripatetic member of school staff.
Date published: 2022-05-09
Rated 1 out of 5 by from Scanner Returned because it did not convert to a M/S word document. Needed to convert to Adobe and then to Word, I would re write the document faster!
Date published: 2022-04-14
Rated 5 out of 5 by from Simple and easy I don't think a scanner could be made any easier to use and it's perfect for documents. Everybody that sees me use it is impressed and several of my co-workers have purchased one because of mine. Two features that have room for improvement: 1. The default name is long, too long, and only the final digits are different. The names all look the same in File Explorer because there's not enough room (no, the name is too long). 2. Sometimes I get the exclamation point and don't know why. Turning the scanner off and on usually clears that.
Date published: 2022-04-12
Rated 1 out of 5 by from Terrible Software The DS-940DW is a lot faster than the 620 and 720 I owned, but the software for the DS-920DW wastes a lot more time the speed of scanning can make up for it. It allows to add some buttons (called Workflow) to scan to specific locations but for some strange reason, it doesn't have a 'continuous' scanning option, which it has for the direct 'Scan' button. So for multiple pages, you can only use the default 'Scan' button where only the last location is saved. There is also no way to backup/save the configuration. So if you use the scanner on a different computer you have to configure all the workflow buttons again. Therefore the scanner is fast, but super slow to scan many documents because of all the stuffing around with the software.
Date published: 2022-04-08
Rated 2 out of 5 by from Disappointing Portable Scanner As a top model should be easier to get it working and regularly shows there's an issue that can rarely figure out what the problem is. Consistent difficulty with getting it to scan and once it is active there's an excessive delay before it will scan. Then trying to find it and place it elsewhere is not that friendly. So, a bit disappointed it is not as user friendly as I had hoped.
Date published: 2022-04-07
Rated 5 out of 5 by from Excellent scanner with awesome features! This scanner was perfect for what I needed. I work for the City and they do not allow you to install software and hardware in their network. You have to have approval from IT which is never allowed. This scanner is fast and quiet. I scanned 14 timesheets in 40 seconds. It can scan in .pdf and .jpeg formats. It scans in black and white or color. You do not need a computer because this scanner can save to a micro SD card, or to a computer via USB or Wifi. The software it came with is not the greatest and the PDF software is like a trial limited version. The instructions are terrible. If you are turning it on, short press the power button for a second. If you are turning it off, long press the power button and hold for at least 6 seconds before you let go. Otherwise it will drive you crazy with lights flashing and nothing happening. This scanner doesn't take up very much room on your desk. One thing you cannot do is scan an open book like a flat bed scanner. The page being scanned has to pass through the scanner, not unless you rip the page out of the book. It cannot read a 128 GB card. The card I have in mine is 8GB and is more than enough. You can transfer your files into your computer using the scanner as an external drive. The price is very affordable for the features it has. Do not forget to buy a protective case to protect your investment. I carry this scanner where ever I go.
Date published: 2022-03-30
Rated 2 out of 5 by from Nice design, but! Do not buy this device if expecting to use with a tablet. It will not charge with included cord into any separate USB plug. I like the compact design and other features but don't have any other means in which to charge as direct by the manufacture.
Date published: 2022-03-04
  • y_2022, m_5, d_24, h_21
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.27
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_41
  • loc_en_GB, sid_DS940DW, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_brother-uk
  • bvseo_sdk, net_sdk, 3.2.0.0
  • CLOUD, getContent, 106ms
  • REVIEWS, PRODUCT

Software

Software for Windows

  • iPS (iPrint&Scan) - Easy to use scan software from Brother offering document workflow management.
  • Nuance® PaperPort SE 14 - Document management & sharing program.
  • Kofax Power PDF Standard v3 - PDF Editor built to maximise productivity.
  • Remote Setup - Allows the user to set-up the scanner from their PC.
  • NewSoft® Presto!® BizCard 6 - A complete contact management solution that lets you scan, edit and synchronize business card contacts to various contact management software applications.

Software for macOS

  • iPS (iPrint&San) - Easy to use scan software from Brother offering document workflow management.
  • Remote Setup - Allows the user to set-up the scanner from their PC.
  • NewSoft® Presto!® BizCard 7 - A complete contact management solution that lets you scan, edit and synchronise business contacts to various contact management software.
