ADS1100W

Perfect for the home office where space is tight

Discontinued Product

ADS1100W

Specifications

General

Usage type Desktop
Multi feed sensor Yes
RAM 128 MB

Connectivity

USB interface High Speed USB 2.0
Wireless network interface Yes

Dimensions & weights

With carton 380 W x 170 D x 207 H mm
With carton 2500 g
Without carton 285 W x 103 D x 84 H mm
Weight 1500 g

Energy Consumption

Operating Up to 14 watts
Ready mode 4 watts
Sleep mode Up to 1.5 watts
Off 0.25 watts
Sound power 59 dB
Sound pressure 47 dBA

Environment

Operating humidity 20 - 80%
Operating temperature 5 - 35°C

Environmental

Energy Star environmental accreditation Yes

In the box

AC adaptor Yes
Power supply cord Yes
Product safety guide Yes
Software disc Driver software for Windows® and Mac OS
USB cable Yes
User guide Yes
Quick setup guide Yes

Media specifications

Types and sizes Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Business Card, Plastic Card
Weights 52 - 110 gsm (multiple sheets)
ADF media sizes Paper (multiple sheets): 51-215.9x70-297mm, Paper (single sheet): 51-215.9x70x863mm, Plastic card: 51-55x70-95mm, Plastic card Thickness: 0.4-0.76mm

Network

IPv4 Yes
Network protocols ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, Custom Raw Port/Port9100, FTP Client and Server, SNMPv1/v2c, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Scan), SNTP Client
Wireless network Built‐in 802.11b/g/n wireless network
Wireless network security APOP, POP before SMTP, SMTP-AUTH, SSL/TLS (HTTPS, SMTP), WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES).
Wireless setup support Yes

Scanning

2-Sided scan Yes
ADF 20
Scan to email, Image, OCR, File, USB
Colour A4 scan speed 16 ppm
Colour depth 30/24 bit
Greyscale 256 levels
ICA compatibility Yes
Interpolated scan resolution 1200 x 1200 dpi
ISIS compatibility Yes
Multi feed detection Yes
Paper sensor Yes
SANE compatibility Yes
Scan resolution from ADF 600 x 600
TWAIN compatibility Windows 7, Windows 8, Windows Vista, Windows XP
WIA compatibility Yes

Warranty

Warranty 12 months
Show more
Show less

Support

Woman sat at a desk on a laptop

Downloads & Drivers

Download and install the latest drivers and software for your Brother products.

View Downloads
Man and a woman sat a desk on a laptop

FAQs

Find the answers to our most frequently asked questions and troubleshooting here.

View FAQs
Man sat on a sofa working on a tablet

Manuals & Guides

Download the latest manuals and user guides for your Brother products

View Manuals
Technical Specifications

Software

This product is equipped with a selection of out-of-the-box and downloadable software that makes scanning easier and improves the content of the final digital output:

Diagram of workflow from smartphone to bundled software to Brother iPrint&Scan app

Brother iPrint&Scan App

Quick and efficient way to get scanned content directly onto smart phones and tablets, giving you the information at your fingertips.

Brother Control Centre 4 software for ADS-2100

Brother Control Center 4 (Windows®) & Control Center 2 (Mac)

Managing the Scan to functions (image, OCR, email and File). Advanced functions include: Auto Deskew, Skip Blank Page, Auto Image rotation and Bleed through prevention/ remove.

Screen shot of BRAdmin Professional software

BRAdmin Pro 3

This software allows system administrators to view and control the status of their networked Brother and most other SNMP compliant printing devices.

Industry Application

Brother Scanners for the Home Office

Home Office

Scanning for the home office allows space saving and gives peace of mind knowing that important files, photos and documents are backed up and can be accessed from mobile devices.

Brother Scanners for the Office Environment

Office

Offices can benefit from scanning a wide range of business documents helping reduce costly storage space and improve business efficiencies. Cut down on insecure hard copies, meet environmental targets, achieve HR data compliance guidelines, enable simple document collaboration and improve business efficiencies.

Customer Reviews

ProductPage is rated 3.4 out of 5 by 9.
Rated 4 out of 5 by from Uso doméstico y pequeña empresa perfecto Yo lo compré hace un par de años y soluciona las necesidades de escaneo. hojas sueltas, escrituras, tickets, a mí si me va bien, a veces si la hoja está un poco deteriorada se puede atascar, pero creo que es la mejor relación calidad-precio que conozco.
Date published: 2019-05-29
Rated 1 out of 5 by from SE ATASCA CONSTANTEMENTE No lo recomiendo para una oficina por más pequeña que sea. Se atasca constantemente y rompe la hoja por la derecha. Según el fabricante no acepta hojas de 90gr, pero el mismo problema lo tiene para los diferentes gramajes
Date published: 2019-05-01
Rated 5 out of 5 by from Klein und Kompakt Für die meinsten Einsatzgebiete vollkommen Einsatzfähig
Date published: 2018-10-22
Rated 2 out of 5 by from Don't bother if you want to scan any quantity I bought this because I didn't want to have to use my computer to scan and the Brother website said that it would scan to Dropbox - it doesn't. After I set it all up and couldn't get it to work, I contacted support and all their support people could do was to tell me to return it because it doesn't scan to web at all. They then updated the website, so at least it is right now. In the hope that I had not wasted my time in setting it up, I thought I would try scanning to USB - I wish I hadn't bothered - it took 1 min 33 seconds to scan and save (mostly save) a 1 sheet, 2 sided document. On the plus side, the scans were of decent quality, but I just can't waste my life waiting for them to save! It is going back.
Date published: 2018-06-15
Rated 4 out of 5 by from Good simple compact desktop scanner This is a great basic scanner for everyday use. It can scan documents double sided very quickly. Obviously this can only be used on sheets of paper, and books etc are not compatible. We have just started a new business and the scanner has saved us a lot of time when it comes to uploading contracts etc.
Date published: 2017-10-23
Rated 1 out of 5 by from Scanner purchase Whilst the scanner was just what I was looking for I am very disappointed the software provided did not allow me to set up the scanner and therefore I am not currently using it until I can find a solution.
Date published: 2017-07-31
Rated 4 out of 5 by from Fast set-up and scanning with difficulties with sheet-fed Easy set up to use in wifi. Fast scanning even with highest resolution of 600dpi. Main point is that the scanner pies not pull in paper straight. With highest resolution paper is pulled through slower - I made a diy construction that ensures a4 paper is fed straight even when using lower dpi. Now it's fine - but brother should be able to come up with a solution on its own. Will be even more important if more pages shall be scanned.
Date published: 2016-09-14
Rated 5 out of 5 by from Great Device I bought this to scan documents for home and work. It is small for storage and very easy to set up. For the cost the speed of the device is very good and the PDF scan quality has been more than acceptable at full speed. There have been one or two paper jams but hat probably had more to do with how I stacked the device rather than an major issue. For the price I think you would struggle to find a faster scanner. It ticks a lot of boxes.
Date published: 2016-02-21
