MFC-8510DN High-Speed Mono Laser All-in-One + Duplex, Fax, Network

Our most affordable 4-in-1 mono laser for the busy office

Supplies

Show more
Show less

Specifications

General

Printer type Mono
Display size Backlit 5 line LCD
Laser classification Class 1 Laser Product (IEC 60825-1:2007)
Max paper size A4
Memory 64MB (expandable up to 320MB using 1 x 144 pin, 16bit DDR2 DIMM)
Processor StarSapphire 400MHz
Technology Laser
Function Print, Copy and Scan, Fax

Connectivity

Connectivity Wired Network
Local interface Hi-Speed USB 2.0
Wired network interface Ethernet (10Base T/100Base-TX)

Mobile connectivity

Supported AirPrint, Cortado Cloud Print, Google Cloud Print™, iPrint & Scan

Copying

2-sided copy No
Resolution Up to 1200 x 600dpi

Dimensions & weights

With carton 533(w) x 515 (d) x 601(h) mm / 19.9kg
Without carton 405(w) x 415(d) x 423(h) mm / 15.8kg

Environmental

Blue Angel environmental accreditation Yes
Nordic Swan environmental accreditation Yes
Sound power 6.64BA active, 6.4BA quiet mode, 4.62BA ready
Sound pressure 59dBA active, 54dBA quiet mode, 37dBA ready
Typical electrical consumption 2.28kWh / week

Faxing

Fax modem 33.6 kbps
Internet fax Yes
PC Fax Send & receive faxes from your PC using a phone line (Receiving is for Windows® only)

In the box

Contents Fax line cord, Power supply cord, Product safety guide, Software disc, Supplies, User guide, Warranty card, Quick setup guide

Media specifications

Types and sizes Standard / Optional Paper Tray - Plain & recycled paper- Multi-Purpose Tray - Plain, recycled & bond paper - ADF (Automatic Document Feeder) Standard / Optional Paper Tray - A4, Letter, B5(ISO/JIS), A5, A5(Long Edge), B6(ISO), A6, Executive, Legal, Folio (A4 only supported in automatic duplex print mode) Multi-Purpose Tray - Width: 76.2mm to 215.9mm (3˝ to 8.5˝) x Length: 127mm to 355.6mm (5˝ to 14˝) ADF (Automatic Document Feeder) - Plain Paper & Recycled Paper
Weights Standard / Optional Paper Tray - (between 60 - 105 g/m2 (16 - 28 lb)) Multi-Purpose Tray - (between 60 - 163g/m2 (16 to 43lb)) ADF (Automatic Document Feeder) 64 - 90 g/m2 (17 - 24 lb) Standard / Optional Paper Tray - (A4 only supported in automatic duplex print mode)

Network

Secure function lock v2 Restrict printing, faxing, copying and scanning activities and assign optional page limits
Wired network Ethernet (10Base-T/100Base-TX)
Wired network security 802.1x - Supported Protocols - EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS

Operating systems & software

Supported Windows® Windows 7® (32 & 64 bit editions), Windows Vista® (32 & 64 bit editions), Windows® XP Professional (32 & 64 bit editions), Windows® XP Home Edition, Windows® Server 2008R2, Windows® Server 2008 (32 & 64 bit editions), Windows® Server 2003 (32 & 64 bit editions). Note that Windows® Server 2003 & 2008 are for printing only. Mac Mac OS X 10.5.8, 10.6.x, 10.7.x or greater Linux CUPS, LPD/LPRng (x86/x64 environment)

Paper handling

Paper input 250 sheet standard paper tray, 50 sheet multi-purpose tray, 35 sheet Automatic Document Feeder (ADF), 500 sheet optional paper tray
Paper output 150 sheets face down 1 sheet face up (straight paper path)

Printing

A4 2-sided print speed Up to 18 sides per minute
A4 standard print speed Up to 36 pages per minute
Resolution 1,200 x 1,200dpi, HQ1200 (2,400 x 600dpi), 600 x 600dpi
Automatic 2 sided print Yes
First print out time Less than 8.5 seconds
Recommended monthly volume 500 to 3,500 pages

Scanning

Resolution 1,200 x 1,200dpi (from flatbed), 1,200 x 600dpi (from ADF), 19,200 x 19,200dpi (Enhanced)
Scanner type CIS
2-Sided scan No

Solutions

Supported AirPrint, b-guard, Br-Docs, BSI, Cortado Cloud Print, Dropbox, Evernote, Google Cloud Print, Google Docs, iPrint & Scan, ISIS, Managed Print Services

Supplies and accessories

Supplies In-box Toner Approx. 2,000 pages. 1 Standard Toner TN-3330 - Approx. 3,000 pages. 1 High Yield Toner TN-3380 - Approx. 8,000 pages. 1 Drum DR-3300 - Approx. 30,000 pages (one job per page)

Warranty

Warranty 1 Year Manufacturers Warranty
