High speed label printer engineered with Bluetooth, wired and wireless interfaces
QL1110NWBZU1
QL1110NWBZU1
USB, Ethernet, Wi-Fi and Bluetooth connectivity with support for MFi and AirPrint
Print labels up to 103.6mm wide from PC, Mac, smartphone or tablet
Store up to 255 label templates in the printer's memory, then access and print using the built-in USB host function
Supports printing of FBA (Fulfilled by Amazon) labels through crop print function
Built-in cutter to create your own length labels using unique continuous rolls
Various SDK (Software Development Kits) available for Windows, iOS and Android devices
This wide format shipping label printer has a 4 inch(101.6mm) print width - to offer maximum compatibility with various shipping label software packages.
Easily send your products to a Fulfilled By Amazon (FBA) warehouse using the crop print function. Simply print the PDF that contains the multiple barcode labels from your FBA account, and let the driver detect, extract and print each individual label to the QL-1110NWB automatically.
With USB, Ethernet, Wi-Fi and Bluetooth, you can choose to print labels from your PC, Mac, smartphone or tablet, whichever is most convenient. Plus with Apple MFi certification and AirPrint, all your connectivity options are covered.
With a range of SDK's (Software Development Kits) for Windows, iOS and Android, the QL-1110NWB can be easily integrated into your own systems and software.
| Maximum label width (mm) | 102mm |
|---|---|
| Database upload from PC | Yes |
| Housing colour | Glossy black and white |
| Image upload from PC | Yes |
| Memory locations | 255 |
| Technology | Direct thermal |
| Template upload from PC | Yes |
| Memory capacity | 7.8 MB |
| Type | DK rolls (DK die-cut labels / DK continuous length tape) |
|---|
| AirPrint | Yes |
|---|---|
| Bluetooth | Ver 2.1 EDR |
| MFi | Yes |
| Bluetooth profiles | SPP/OPP/BIP/HCRP |
| USB interface | Ver 2.0 (full speed) |
| Wi-Fi Direct | Yes |
| Wired network interface | 10/100 BASE-TX |
| Wireless network interface | IEEE 802.11 b/g/n |
| Dimensions | 170mm (W) x 222mm (D) x 151mm (H) |
|---|---|
| Weight | 1.71 kg |
| Power supply cord | Yes |
|---|---|
| Supplies | 103mm x 164mm large shipping labels (41 labels) - 62mm continuous length paper tape (8.1 metres) |
| USB cable | Yes |
| User guide | Yes |
| Warranty card | Yes |
| Quick setup guide | Yes |
| Wireless network security | WEP, WPA-PSK/WPA2-PSK (TKIP/AES), LEAP (CKIP), EAP-FAST (TKIP/AES), PEAP (TKIP/AES), EAP-TTLS (TKIP/AES), EAP-TLS (TKIP/AES) |
|---|
| Macintosh | Mac OS X 10.11.x or higher, Mac OS X 10.12.x or higher, Mac OS X 10.13.x or higher, Mac OS X 10.14.x or higher |
|---|---|
| Windows | Server 2008, Server 2008R2, Server 2012, Server 2012R2, Server 2016, Windows 7, Windows 8, Windows 8.1, Windows 10 |
| 1 dimensional barcode symbologies | CODE39, CODE128, UCC/EAN-128(GS1-128), ITF(I-2/5), CODABAR(NW-7), UPC-A, UPC-E, EAN13(JAN13), EAN8, GS1 DataBar(RSS)(GS1 DataBar Omnidirectional,GS1 DataBar Truncated,GS1 DataBar Stacked,GS1 DataBar Stacked Omnidirectional,GS1 DataBar Limited,GS1 DataBar Expanded,GS1 DataBar Expanded Stacked) |
|---|---|
| 2 dimensional barcode symbologies | PDF417(Standard, Truncate, Micro), QR Code(Model 1, Model 2, Micro), Data Matrix (ECC200 Square, ECC200 Rectangular), MaxiCode, CODE93, POSTNET, UPC-E EXTENTION, MSI, Aztec |
| Bitmap fonts | Helsinki, Brussels, Letter Gothic Bold, San Diego, Brougham |
| Maximum label width | 103.6 mm |
| Maximum print length | 3000 mm |
| Maximum print width | 101.6 mm |
| Outline/Vector fonts | Helsinki, Brussels, Letter Gothic |
| Resolution (dpi) | 300 x 300 |
| Standard print speed | 110 mm per second |
| Database file compatibility | csv, Microsoft Access, Microsoft Excel |
|---|---|
| Date and time stamp | Date and time |
| Fonts | All installed truetype fonts |
| Frames | 126 |
| Label orientations | Horizontal, Vertical |
| Microsoft Office add-in (highlight->click->print) | Excel, Outlook, Word |
| Screen capture | Yes |
| Sequential numbering | 1 - 9999 / A - Z / a - z |
| Text alignment | Centre, Justify, Left, Right |
| Typestyles | Bold, Horizontal lines, Invert, Italic, Normal, Shadow, Shadow light, Surround |
| Vertical print | Yes |
| SDK (Software Development Kit) | Yes |
|---|
| Warranty | 3 year back to base warranty (upon registration) |
|---|
Download and install the latest drivers and software for your Brother products.
View Downloads
The QL-1110NWB is the ideal label printer for mail rooms, warehouses, and anyone who needs to print high quality shipping labels containing barcodes, images and text.
Easily print labels suitable for sending your products to Amazon fulfilment centres using the crop print function in the driver. After Amazon creates your PDF containing the barcode labels to attach to your products, tick "crop print" in the driver to automatically extract each individual label from the A4 sheet, and print to individual labels on the QL-1110NWB.
To ensure maximum compatibility with third party shipping label printing software, the QL-1110NWB has a print width of 4" (101.6mm) - the specification required by the majority of parcel carriers.
PC and Mac users can connect via USB, wired ethernet or by Wi-Fi. Or easily connect your mobile device using Bluetooth. For full compatibility with Apple devices, the QL-1110NWB is MFi certified, and also includes AirPrint.
Connect directly to specialist equipment using the USB host port - no PC required. These devices can then send commands to select the required label template stored in the printer memory, send the required data to merge onto the label, then issue the command to print. One example is to scan barcodes containing the commands to select and print the built-in templates, to print copies of barcodes
The free P-touch Editor label design software for PC and Mac lets you add text, images, barcodes and frames to your labels. Or use the free iPrint & Label app for iOS and Android to create and wirelessly print labels from your mobile devices.
The P-touch editor add-in for Microsoft Office (Windows only) allows you to select and print data directly from Word, Excel and Outlook. From Microsoft Word, highlight an address and click the add-in, in the toolbar, to print this on a label. Highlight cells in Excel and again click the add-in. For Outlook, select the contact with the address you require to print this label.
Brother provides free software development kits for Windows, iOS and Android for system developers to easily incorporate the QL-1110NWB into legacy software.
Brother DK rolls slot-in easily for fast label changes. Several types are available:
