High-speed label printer engineered to print up to 4" wide labels
QL1100ZU1
QL1100ZU1
Print labels up to 103.6mm wide and at up to 110mm/second print speed
USB connectivity for PC and Mac
Store up to 99 label templates in the printer's memory, then access and print using the built-in USB host function
Supports printing of FBA (Fulfilled By Amazon) labels through a special PDF crop print function
Built-in cutter to create your own length labels using unique continuous rolls
Windows SDK (Software Development Kit) available to add label printing to your own apps
Featuring a 4 inch width (101.6mm) print head, the QL-1100 offers maximum compatibility with third party shipping label software packages from couriers and parcel delivery companies.
And for sellers who use the Fulfilled by Amazon (FBA) service, the “crop-print” feature enables you to print multiple barcode labels contained in the PDF generated by your Fulfilled by Amazon account. The driver detects, extracts and prints each individual label to the QL-1100 automatically, making it easy to mark up your items to be shipped to Amazon.
This printer has full PC and Mac compatibility thanks to its USB connection, and the free P-touch Editor label design software lets you add text, images and barcodes to your labels.
The QL-1100 can easily be integrated into your own systems and software using the Windows SDK (Software Development Kit).
| Maximum label width (mm) | 102mm |
|---|---|
| Database upload from PC | Yes |
| Housing colour | Glossy black and white |
| Image upload from PC | Yes |
| Memory locations | 99 |
| Technology | Direct thermal |
| Template upload from PC | Yes |
| Memory capacity | 7.8 MB |
| Type | DK rolls (DK die-cut labels / DK continuous length tape) |
|---|
| USB interface | Ver 2.0 (full speed) |
|---|
| Dimensions | 170mm (W) x 222mm (D) x 151mm (H) |
|---|---|
| Weight | 1.71 kg |
| Power supply cord | Yes |
|---|---|
| Supplies | 103mm x 164mm large shipping labels (41 labels) - 62mm continuous length paper tape (8.1 metres) |
| USB cable | Yes |
| User guide | Yes |
| Warranty card | Yes |
| Quick setup guide | Yes |
| Macintosh | Mac OS X 10.11.x or higher, Mac OS X 10.12.x or higher, Mac OS X 10.13.x or higher, Mac OS X 10.14.x or higher |
|---|---|
| Windows | Windows 7, Windows 8, Windows 8.1, Windows 10 |
| 1 dimensional barcode symbologies | CODE39, CODE128, UCC/EAN-128(GS1-128), ITF(I-2/5), CODABAR(NW-7), UPC-A, UPC-E, EAN13(JAN13), EAN8, GS1 DataBar(RSS)(GS1 DataBar Omnidirectional,GS1 DataBar Truncated,GS1 DataBar Stacked,GS1 DataBar Stacked Omnidirectional,GS1 DataBar Limited,GS1 DataBar Expanded,GS1 DataBar Expanded Stacked) |
|---|---|
| 2 dimensional barcode symbologies | PDF417(Standard, Truncate, Micro), QR Code(Model 1, Model 2, Micro), Data Matrix (ECC200 Square, ECC200 Rectangular), MaxiCode, CODE93, POSTNET, UPC-E EXTENTION, MSI, Aztec |
| Bitmap fonts | Helsinki, Brussels, Letter Gothic Bold, San Diego, Brougham |
| Maximum label width | 103.6 mm |
| Maximum print length | 3000 mm |
| Maximum print width | 101.6 mm |
| Outline/Vector fonts | Helsinki, Brussels, Letter Gothic |
| Resolution (dpi) | 300 x 300 |
| Standard print speed | 110 mm per second |
| Database file compatibility | csv, Microsoft Access, Microsoft Excel |
|---|---|
| Date and time stamp | Date and time |
| Fonts | All installed truetype fonts |
| Frames | 126 |
| Label orientations | Horizontal, Vertical |
| Microsoft Office add-in (highlight->click->print) | Excel, Outlook, Word |
| Screen capture | Yes |
| Sequential numbering | 1 - 9999 / A - Z / a - z |
| Text alignment | Centre, Justify, Left, Right |
| Typestyles | Bold, Horizontal lines, Invert, Italic, Normal, Shadow, Shadow light, Surround |
| Vertical print | Yes |
| SDK (Software Development Kit) | Yes |
|---|
| Warranty | 3 year back to base warranty (upon registration) |
|---|
Download and install the latest drivers and software for your Brother products.
View Downloads
The QL-1100 wide format shipping label printer is the ideal solution for small businesses and those that work from home and need to ship products and parcels. Print high quality shipping labels containing barcodes, images and text.
Easily print labels suitable for sending your products to Amazon fulfilment centres using the crop print function in the driver. After Amazon creates your PDF containing the barcode labels for attaching to your products, select the “crop print” function in the print options to automatically extract each barcode label from the A4 sheet and then prints the individual labels from the QL-1100.
To ensure maximum compatibility with third party shipping label printing software, the QL-1100 has a print width of 4" (101.6mm) - the specification required by the majority of parcel carriers.
The free P-touch Editor label design software for PC and Mac lets you add text, images, barcodes and frames to your labels. Link to data contained in an Excel spreadsheet or .csv file, then merge the data onto your label layout to quickly print many labels at once.
The P-touch editor add-in for Microsoft Office (Windows only) allows you to select and print data directly from Word, Excel and Outlook. From Microsoft Word, highlight an address and click the add-in, in the toolbar, to print this on a label. Highlight cells in Excel and again click the add-in. For Outlook, select the contact with the address you require to print this label.
Connect directly to specialist equipment using the USB host port - no PC required. These devices can then send commands to select the required label template stored in the printer memory, send the required data to merge onto the label, then issue the command to print. One example is to scan barcodes containing the commands to select and print the built-in templates, to print copies of barcodes
Easily incorporate the QL-1100 into your existing legacy software. Brother b-PAC is a free SDK (software development kit) for Windows based applications.
Brother DK rolls slot-in easily for fast label changes. Several types are available:
